Implementation

compute_control

    def compute_control(cur_pose, prev_pose):
    """ Given the current and previous odometry poses, this function extracts
    the control information based on the odometry motion model.

    Args:
        cur_pose  ([Pose]): Current Pose
        prev_pose ([Pose]): Previous Pose

    Returns:
        [delta_rot_1]: Rotation 1  (degrees)
        [delta_trans]: Translation (meters)
        [delta_rot_2]: Rotation 2  (degrees)
    """
    cur_x, cur_y, cur_theta = cur_pose
    prev_x, prev_y, prev_theta = prev_pose

    delta_rot_1 = mapper.normalize_angle(np.degrees(np.arctan2(cur_y - prev_y, cur_x - prev_x)) - prev_theta,)
    delta_trans = np.hypot(cur_y - prev_y, cur_x - prev_x)
    delta_rot_2 = mapper.normalize_angle(cur_theta - prev_theta - delta_rot_1)

    return delta_rot_1, delta_trans, delta_rot_2

The compute_control() function converts robot movement into the odometry motion model by comparing two poses. This model breaks any movement into three sequential steps.

1. Initial rotation (δrot1): The robot turns to face its destination

2. Translation (δtrans): The robot moves forward in a straight line

3. Final rotation (δrot2): The robot adjusts to reach the final orientation

Using pose tuples (x, y, θ) as inputs, the function calculates these parameters with NumPy's arctan2 and hypot functions, normalizing all angles to [-180°, 180°]. This representation allows us to accurately model and predict the robot's movement through space.

odom_motion_model

def odom_motion_model(cur_pose, prev_pose, u):
""" Odometry Motion Model

Args:
    cur_pose  ([Pose]): Current Pose
    prev_pose ([Pose]): Previous Pose
    (rot1, trans, rot2) (float, float, float): A tuple with control data in the format
                                                format (rot1, trans, rot2) with units (degrees, meters, degrees)


Returns:
    prob [float]: Probability p(x'|x, u)
"""
delta_rot_1, delta_trans, delta_rot_2 = compute_control(cur_pose, prev_pose)

prob_rot_1 = loc.gaussian(delta_rot_1, u[0], loc.odom_rot_sigma)
prob_trans = loc.gaussian(delta_trans, u[1], loc.odom_trans_sigma)
prob_rot_2 = loc.gaussian(delta_rot_2, u[2], loc.odom_rot_sigma)

return prob_rot_1 * prob_trans * prob_rot_2

The odom_motion_model() function calculates the probability of transitioning between poses by comparing actual and theoretical movements. First, it extracts the three odometry parameters (initial rotation, translation, final rotation) from both:

- The "actual" path taken by the robot based on sensor readings

- The "theoretical" path needed to move between any two grid states

It then treats each parameter as an independent Gaussian probability distribution, with means centered on the ideal movements and standard deviations representing expected motion noise. By multiplying these three probabilities together, we get the likelihood that the robot moved from a specific previous state to the current state given the recorded control input. This probabilistic approach handles the inherent uncertainty in robot movement.

prediction_step

def prediction_step(cur_odom, prev_odom):
""" Prediction step of the Bayes Filter.
Update the probabilities in loc.bel_bar based on loc.bel from the previous time step and the odometry motion model.

Args:
    cur_odom  ([Pose]): Current Pose
    prev_odom ([Pose]): Previous Pose
"""
u = compute_control(cur_odom, prev_odom)

loc.bel_bar = np.zeros((mapper.MAX_CELLS_X, mapper.MAX_CELLS_Y, mapper.MAX_CELLS_A))

for prev_x in range(mapper.MAX_CELLS_X):
    for prev_y in range(mapper.MAX_CELLS_Y):
        for prev_theta in range(mapper.MAX_CELLS_A):
            if (loc.bel[prev_x, prev_y, prev_theta] < 0.0001): continue

            for cur_x in range(mapper.MAX_CELLS_X):
                for cur_y in range(mapper.MAX_CELLS_Y):
                    for cur_theta in range(mapper.MAX_CELLS_A):
                        p = odom_motion_model(
                            mapper.from_map(cur_x, cur_y, cur_theta),
                            mapper.from_map(prev_x, prev_y, prev_theta),
                            u
                        )

                        loc.bel_bar[cur_x, cur_y, cur_theta] += p * loc.bel[prev_x, prev_y, prev_theta]

loc.bel_bar /= np.sum(loc.bel_bar)

The prediction_step() function calculates the robot's probable locations after movement by:

1. Extracting the actual movement parameters from odometry readings

2. Computing a new belief distribution by systematically examining all possible state transitions

3. For each current grid cell (x, y, θ), it evaluates the probability of arriving there from every previous cell

4. These probabilities are multiplied by the previous belief values and summed to create the predicted belief bel―

sensor_model

def sensor_model(obs):
""" This is the equivalent of p(z|x).
Args:
    obs ([ndarray]): A 1D array consisting of the true observations for a specific robot pose in the map
Returns:
    [ndarray]: Returns a 1D array of size 18 (=loc.OBS_PER_CELL) with the likelihoods of each individual sensor measurement
"""
return [loc.gaussian(obs[i], loc.obs_range_data[i], loc.sensor_sigma)
    for i in range(mapper.OBS_PER_CELL)]

This function takes an array of true observations (obs) for a specific robot pose It returns an array of 18 values (one for each sensor measurement direction) Each value represents the likelihood of that sensor reading given the true state It uses a Gaussian distribution with mean = the true observation value and standard deviation = loc.sensor_sigma

update_step

def update_step():
""" Update step of the Bayes Filter.
Update the probabilities in loc.bel based on loc.bel_bar and the sensor model.
"""
for cur_x in range(mapper.MAX_CELLS_X):
    for cur_y in range(mapper.MAX_CELLS_Y):
        for cur_theta in range(mapper.MAX_CELLS_A):
            p = sensor_model(mapper.get_views(cur_x, cur_y, cur_theta))
            loc.bel[cur_x, cur_y, cur_theta] = np.prod(p) * loc.bel_bar[cur_x, cur_y, cur_theta]

loc.bel /= np.sum(loc.bel)

The update_step() function implements the update phase of the Bayes Filter. It iterates through every possible robot position in the discretized environment (x, y coordinates and orientation θ) and updates the posterior belief (loc.bel) based on the predicted belief (loc.bel_bar) and current sensor measurements. For each potential position, the function:

1. Retrieves the expected observations using mapper.get_views()

2. Calculates the likelihood of the actual sensor readings using sensor_model()

3. Computes the product of these individual sensor likelihoods using np.prod(p)

4. Multiplies this likelihood by the prior belief (loc.bel_bar) for that position

5. Finally normalizes the entire belief distribution to ensure it sums to 1

This updated posterior belief represents the robot's refined estimation of its position after incorporating both motion prediction and sensor information, completing one full cycle of the Bayes Filter.

Simulation

Here is a video that shows a trajectory and localization simulation without a Bayes filter. We can tell that the odometry model is not great, as it wanders outside of the bounds of the map.

Here are two videos of successful localization runs with Bayes.

Notes and Conclusion

I referenced Stephen Wagner's lab report, and got some help from Sana Chawla.
